Vertical Laminar Air Flow – Cleanroom Equipment Solutions

We provides high-quality Horizontal Laminar Air Flow solutions designed to create a clean, controlled working environment for contamination-sensitive laboratory applications. These systems deliver a continuous flow of filtered air horizontally across the work area, helping protect critical materials and processes from airborne contaminants.

Our Horizontal Laminar Air Flow systems are suitable for pharmaceutical laboratories, biotechnology, microbiology, diagnostic laboratories, research and development facilities, electronics, and other controlled environments where clean working conditions are essential.

Waldain Technologies focuses on practical, reliable, and application-oriented cleanroom equipment. Our systems can be configured according to specific laboratory requirements, including working dimensions, construction materials, filtration arrangements, lighting, and other operational features.

Designed with ease of operation, cleanliness, and durability in mind, Horizontal Laminar Air Flow systems can support consistent laboratory workflows and help maintain a controlled work zone. They are particularly useful for applications requiring protection of products, samples, and sterile materials from environmental contamination.
Whether you are establishing a new laboratory or upgrading an existing facility, Waldain Technologies Pvt. Ltd. offers customized cleanroom equipment solutions to meet your operational needs.

Specifications

Brand Name	WALDAIN
Air cleanliness	ISO Class 5 (ISO 14644-1:1999 (E))
Air Velocities	0.45 ± 0.05 mps
Air Flow	Vertical
Noise Level	Less than 67 dB
Vibration Level	Minimum
Light intensity	> 300 lux
Power Supply	230V AC 1-Ø 50HZ

Laminar Air Flows are designed to offer the highest product protection for samples and processes by providing ISO Class 5 particle free work area. The LAFs with various air-flow patterns offer proven protection for the samples and processes. The work area is continuously supplied with positive pressure HEPA filtered air flow.

General Specifications :

• Two Stage filtration
• EU6 – Prefilter (95% down to 5 micron)
• EU14 - HEPA Filter – (99.999% down to 0.3 micron) at supply position
• Statically & Dynamically balanced Motor-blower with suspension arrangement to reduce noise level
• SS work table with due reinforcement
• Glass side panels
• Fluorescent Lights with Milky White Diffuser
• Differential Pressure Gauge : 1 No
• ON/OFF Switches
• Clean Down Timer with Operation HOLD indicator
• DOP Test Port
• 5/15 Amp Switch Socket for external equipment

Options and Accessories :

A wide range of configurations to suit any containment application :

• Front doors (hinged/pneumatic cylinder)
• U. V. Light with Hour Meter
• Air / Gas Cock
• Night Mode Operation
• Velocity display with alarms (audible and visible)
• Filter blocked alarms (audible and visible)
• Explosion proof electrics for Flame-proof applications
